Charger Components
• Shock hazard – make sure the plug is fully inserted into the wall outlet so
that there are no exposed blade surfaces.
• Children should be supervised when in the vicinity of the charger while
plugged in.
• To reduce the risk of fire, connect only to a circuit provided with 30 amps
maximum branch circuit overcurrent protection.
LED Display
NEMA
14-50 Plug
Charging Coupler
Release Button
Charging Display Information
1. Real-time current
2. Power input
3. Power output
4. Charge timer
5. Operating temperature
6. Charging status
7. Rated current
8. Faulty message
9. Faulty indicator
8
9
2
3
4
5
1
6
7
J1772 Plug
