Version 05112017
5
RGB DMX Stick 3 Controller
120-277V
AC Power
RGB Tape Light
RGB Tape Light
RGB Tape Light
CAT-5
CAT-5
CAT-5
RGB Hardwire Connector
RGB Hardwire Connector
RGB Hardwire Connector
RGB DMX Decoder
RGB DMX Decoder
RGB DMX Decoder
RGB DMX
Terminator
120-277V
AC Power
120-277V
AC Power
Complete System Wiring Diagram
