The rst row of edging should include the appropriate number of 4ft edge strips with power connec-
tion depending on the oor size (see component cross reference chart on page 3). When selecting the
power supply, please consult the chart included in this user guide. Up to (and including) 24ft x 24ft oor
systems require a 500W power supply. Systems 26ft x 26ft up to 30ft x 30ft use a 750W power sup-
ply. Danceoor systems over 32ft x 32ft require a 1000W power supply. Systems 40ft x 40ft and over
require a 1500W power supply.
CAUTION: Care should be taken to ensure the power connection between each oor panel is correctly
aligned. Failure to do so may result in an open or short circuit fault condition.
Operating instructions
First Panel
PSU
Second Panel
Power Edge
First Panel Second Panel
PSU
