Section 3
OPERATION
3-7
785 Motor Grader
ITEM NO. NAME TYPE FUNCTION
1 Washer Fluid Reservoir Provides storage for the windshield washer fluid.
2 TEMP Switch Rotary Adjusts the output temperature of the air
switch conditioner.
3 A/C On/Off Switch 2-Position Turns air conditioner On or Off.
toggle
switch
4 Fan Speed Rotary Adjust speed of blower fan.
switch
5 Vent Opening Output vent for the air conditioner output air.
6 Cup Holder Hold drinking cup.
TABLE 3-2. AIR CONDITIONING CONTROL PANEL (see Figure 3-2)
