Section 3
OPERATION
3-9
785 Motor Grader
ITEM NO. NAME TYPE FUNCTION
1 FUEL Gauge Gauge Indicates the amount of fuel remaining in the
tank.
2 Articulation Gauge Gauge Indicates degrees of articulation both left and
right.
3 Engine Water Gauge Indicates the temperature of the water in the
Temperature Gauge engine cooling system.
4 Engine Oil Pressure Gauge Indicates engine oil pressure.
Gauge
5 Total Time Display Indicates total operating time of the Engine.
Module
6 Transmission Gauge Indicate the temperature of the transmission fluid.
Temperature Gauge
7 Engine RPM Gauge Indicate engine RPM.
TABLE 3-3. GAUGE PANEL (see Figure 3-3)
