Section 3
OPERATION
3-11
785 Motor Grader
ITEM NO. NAME TYPE FUNCTION
1 L SIGNAL R Switch 3- Position Activates either Left or Right Turn signals.
toggle
switch
2 Left Turn Indicator Indicator Flashes to indicate the Left turn lights are
light operating.
3 Transmission Warning Indicator Illuminates to indicate when the transmission oil
Indicator light temperature is too high.
4 Low Brake Pressure Indicator Illuminates to indicate the brake pressure is
Indicator light too low.
5 Air Cleaner Restriction Indicator Illuminates to indicate the air cleaner needs to
Indicator light be serviced.
6 Park Brake Indicator Indicator Illuminates when the Parking Brake is applied.
light
7 Right Turn Indicator Indicator Flashes to indicate the Right turn lights are
light operating.
8 BEACON Light Switch Two Turns Beacon Light On or Off.
position
toggle
switch
9 Hazard Light Switch Two Turns Hazard Lights On or Off.
position
toggle
switch
TABLE 3-4. WARNING INDICATORS AND LIGHT SWITCH PANEL (see Figure 3-4)
