Section 4
MAINTENANCE
4-36
785 Motor Grader
TURN SIGNAL PANEL WIRING LEGEND (sheet 3 of 3)
TURN SIGNAL PANEL WIRING SCHEMATIC (sheet 3 of 3)
ITEM PART NUMBER DESCRIPTION QUANTITY
1 160035 FLASHER, TURN SIGNAL 635/685 1
2 33600 TERM, PUSH ON, 0.25, FEMALE, 16-14 GA 1
3 35004 DIODE, 3 AMP, PLASTIC 4
4 36348 TERM, PUSH ON, 0.25, MALE, 18-14, SLV 1
5 39140-09 OVERLAY 6
6 39140-10 LIGHT, EURO, SMOKED, GRN/RED 6
7 39140-11 SWITCH, ROCKER, PADDLE, DPDT 1
8 39140-14 SWITCH, ROCKER, AMBER, SPST 1
9 39140-18 SWITCH, ROCKER, AMBER, DPDT 1
10 981809 PLATE, LIGHT PANEL 1
11 982448 TERM, SOC, DEUTSCH, 16 AWG 10
12 983202 CONN, SOC, 4P, DEUTSCH 1
13 983205 CONN, PLUG, 6P, DEUTSCH 1
14 983212 CONN, WEDGE, PLUG, 4P, DEUTSCH 1
15 983214 CONN, WEDGE, PLUG, 6P, DEUTSCH 1
16 983275 ELECTRICAL SERVICE INDICATOR 1
