9.3.4 Wake Up Command
A) Press the study key three times for the Door/Window sensor to send a Wake Up Notification to the
Gateway. Please make sure the Door/Window Sensor is added to the Z-wave network.
B) How to use Wake Up Interval Set Command to set the Door/Window Sensor to automatic Wake Up.
1. When the configured value is set 0~59 then the configuration is not available and the Wake Up
time cannot be changed.
2. If the configured value is 60~119 then the Wake Up Interval time is 60 seconds.
3. If the configured value is 120~179 then the Wake Up Interval time is 120 seconds.
Note: You can set additional configured values for longer Wake Up Interval times.
C) Wake Up Interval Capabilities Report CC
• Minimum Wake Up Interval Seconds = 60 seconds
• Maximum Wake Up Interval Seconds = 2678400 seconds=31 days
• Default Wake Up Interval Seconds = 600 seconds
• Wake Up Interval Step Seconds = 60 seconds
9.3.5 Battery Command
A) If the Controller or Gateway sends the Battery Get command to the Door/Window Sensor then
Door/Window Sensor will report the Battery Power Level to the Controller or Gateway.
• If the Battery Voltage >3.0V the Battery Power Level is 100%.
• If the Battery Voltage<2.3V the Battery Power Level is 0%.
B) If the Battery has a low voltage of 10%, or less, the Configuration 0x0A setting threshold values for the
Door/Window Sensor will report Battery Report 0xFF to Association Group 1.
9.3.6 Notification Commands
A) Notification Supported Report : Access Control (0x06)、Home Security (0x07)
B) Event Supported Report Command
