1. Remove the fuel tank cap by turning it
counterclockwise.
2.The fuel tank cap
○
2
is prowided with
an air vent knob
○
1
to stop fuel flow.The air
vent knob must be turned to"ON".This will
allow fuel to flow to the
carburetor and the engine to run.
When the engine is not in use. turn the air
vent knob to "OFF" to stop fuel flow.
Ground terminal
○
1
connects the earth
line for prevention of electric shock.When
the electric device is earthed,always the
generator must be earthed.
Parallel Operation Outlets
This is the terminal
○
1
for connecting
special cables for parallel running of two
generator. The parallel running requires
two generator and the special cables. (The
rated output in parallel running is 3.0Kva
and the rated current is
25.0A/120V;13.0A/230V.)
The handing,operation procedure and the
notes on usage are described in the
PARALLEL RUNNING KIT
OWNER'SMANUAL included in the Parallel.
Control Function
Inverter Generator Owner's Manual
