lefeirc SN-L User Manual

SN-L user manual
10
2.4 MAX PITCH ANGLE
2.5 RTH ALT The lowest altitude in the home mode, when the aircraft returns, it will hover according to this height
2.6 HOVER RADIUS
2.7 MIN GROUND SPEED When airspeed is connect
2.8 TAKE-OFF SPEED In the home mode, trigger the speed at which the motor starts (ground speed); used to assist the takeoff;
hand throw 3-5m / s; ejection 15m / s;
0： shake airplane start motors
2.9 CURISING SPEED
3.0 CURISING BASE THR
3.1 CURISING MAX THR
3.2 FAILSAFE TIME 0-3s ①
① For example, if it is set to 3s, when the remote control is out of control, wait for 3s before entering the failsafe
mode（RTH mode）.
② The faster the speed, the smaller the servo PID sensitivity should be.
 OSD
4.8 RC CHANNEL TYPE MODE1: JAPAN, MODE2:AMERICA
4.9 AAT（auto antenna tracking） Open or close AAT function
5.1 LANGUAGE(语言) EN： English
 SENSOR
3.1 CALI LEVEL&GYRO
Keep the aircraft level, and still
3.2 CALI BATT
3.3 CALI COMPASS NO NEED
RSSI CHANNEL RSSI CHANNEL：“0”= Independent RSSI channel wiring
“1-17”= Map the corresponding RC channel
“18”=auto calculate RSSI（SBUS）
3.4 CALI RSSI
九、 Firmware upgrade
The way of get firmware and user manual:
www.lefeirc.com
https://github.com/HelloLeFei/SN_L/releases
Step1: Download upgrade software and drivers and install：install “CP210x USB to UART Bridge” driver.
Step2: download firmware：
Step3: open GCS software：

lefeirc SN-L Specifications

General

Brand	lefeirc
Model	SN-L
Category	Controller
Language	English
