From To
Left channel of preamp output Processor Input 1 and Input 3*
(use Y adapter)
Right channel of preamp output Processor Input 2 and Input 4*
(use Y adapter)
Processor Output 1 Left Aeris rear panel Bass Input (XLR)
Processor Output 2 Left channel input to amplifier driving Aeris upper range
Processor Output 5 Right Aeris rear panel Bass Input (XLR)
Processor Output 6 Right channel input to amplifier driving Aeris upper range
*The redundant feed of left and right input signals to the processor allows a low frequency correction algorithm to be ap-
plied. This compensates for the decrease in channel separation at longer wavelengths in listening rooms. This algorithm
may be defeated at any time by muting inputs 3,4 on the processor’s front panel.
Speaker Connections
XP-4080 Processor Cable Connections
For use with standalone amplifiers
