XP-4080 Processor Cable Connections
From To
(use Y adapter)
(use Y adapter)
*The redundant feed of left and right input signals to the processor allows a low frequency correction algorithm to be ap-
plied. This compensates for the decrease in channel separation at longer wavelengths in listening rooms. This algorithm
may be defeated at any time by muting inputs 3,4 on the processor’s front panel.
Speaker Connections
For use with integrated amplifiers
Left channel pre-out of integrated Processor Input 1 and Input 3*
Right channel pre-out of inegrated Processor Input 2 and Input 4*
Processor Output 1 Left Aeris rear panel Bass Input (XLR)
Processor Output 2 Left channel amp in on integrated amp driving Aeris upper range
Processor Output 5 Right Aeris rear panel Bass Input (XLR)
Processor Output 6 Right channel amp in on integrated amp driving Aeris upper range
