Legacy Levelwind L8305 User Manual

Extra stop is
cut off - not
used
Install pawl and spring in this
position, and mode switch on
outside of sideplate in the
position shown below
Push pawl to stop as shown
above, and be sure mode
switch lever on outside of
sideplate in position shown
below
Back of
Sideplate
Back of
Sideplate
Front of
Sideplate
Front of
Sideplate
Be sure spring is not
binding against
inside of cover plate
