5
3. Input Connections
Signal input from your preamplifier is made through one gold plated RCA
(unbalanced) or one XLR (balanced) type connector per channel. Do not
use both RCA and XLR connectors at the same time as they will load
each other improperly.
4. Output Connections
Signal output to your speaker is made through heavy duty gold plated five
way binding posts that are doubled up to provide bi-wiring capability. Be
sure of correct speaker phasing by matching the + on the amplifier to the +
on the speaker and the -on the amplifier to the - on the speaker.
5. Electrical Protection
The AC line voltage is preset at the factory but may be changed by your
Legacy dealer. Also, there is an AC line fuse and internal rail fuses, but
these too should be changed by your Legacy dealer since the failure of
these parts may indicate a further problem.
