Legacy VALOR User Manual

Wavelet Preamplifier/DAC/Crossover/Room Correction Processor
Inputs
Analog
 Two pairs of Stereo balanced inputs on XLR connectors.
Input sensitivity without attenuation 0 dBFS
*1
= 1 dBV
*2
, input impedance 20 kOhm.
Analog attenuation available in three steps of -3 dB, -6 dB and -12 dB for an input sensitivity of respectively 0 dBFS = 4 dBV, 7 dBV or 12dBV.
 Two pairs of Stereo unbalanced inputs on RCA connectors.
Input sensitivity without attenuation 0 dBFS
*1
= 1 dBV
*2
, input impedance 100 kOhm.
Analog attenuation available in three steps of -3 dB, -6 dB and -12 dB for an input sensitivity of respectively 0 dBFS = 4 dBV, 7 dBV or 12dBV.
 One XLR Measurement microphone input, 48 Vdc Phantom power.
Digital
 Asynchronous USB audio, 24 bit, 44.1 – 96 kHz, PCM up to 352.8 kHz.
 SPDIF, 24 bit, 44.1-96kHz
 TosLink, 24 bit, 44.1-96kHz
22 of 50
