Lehle DUAL EXPRESSION User Manual

11
LEHLE GmbH · Germany · www.lehle.com · support@lehle.com
5. LED OF THE POWER SOCKET
This LED shows that your pedal is active.
Congratulations: The white LED shows
you that the LEHLE DUAL EXPRESSION
has started correctly and is active.
If you move the rocker of the pedal, a
blue LED instead of the white LED indi-
cates that data is being sent via the sock-
ets (2 and 3).
6. BUTTON FOR 10K SOCKET
Here you can change the mode of the
10K socket.
Press this soft touch button to select if the
10K socket (3) should provide expression
data (TRS/RTS/TS) or work as a latching
switch or momentary switch.
In Factory setting the Polarity Autodetec-
tion is selected, to automatically switch
between TRS, RTS or TS.
You will find out how to change the socket
modes and what these are doing at point
“3. 10K SOCKET” on page 9.
7. BUTTON FOR 50K SOCKET
Here you can change the mode of the
50K socket.
Press this soft touch button to select if the
50K socket (2) should provide TRS, RTS
or TS expression data.
In Factory setting the Polarity Autodetec-
tion is selected to automatically switch
between TRS, RTS or TS.
You will find out how to change the socket
modes and what these are doing at point
“2. 50K SOCKET” on page 8.
RTS/TRS
RTS/TRS
