6. BASE AND FIXING
If required, mount the P-SPLIT STEREO to
a pedalboard using the mounting kit.
The P-SPLIT STEREO can be mounted to
a plate such as a pedalboard using the
two holes in the bottom of the pedal.
You can find the optional LEHLE Mount-
ing Kit V3 (order number 100981) online
at www.lehle-components.com.
To mount, undo the four housing screws
by using a 2.5 mm Allen Key and detach
the cover.
Then fix the device base to a base plate
using the two screws, the washers and the
spacers of the Mounting Kit.
Attach the cover and tighten the four
housing screws - done!
For flexible solutions we recommend us-
ing 3M Dual Lock™ instead of Velcro for
stability, which you can also find in handy
sizes at www.lehle-components.com
6 6
!
If you are using the Velcro / Dual Lock™
method, please make a note of the serial
number on the bottom of the pedal be-
fore you cover it, in case you have a sup-
port question for us later and don‘t fancy
dismantling your board!
