SPECIFICATIONS
MODEL BV025HH
ENGINE TYPE
AIR COOLED 4-CYCLE
DISPLACEMENT
25.4 CC
OPERATING R.P.M.
6,800-9,300 R.P.M.
IDLE SPEED
3,000-3,400 R.P.M.
IGNITION TYPE
ELECTRONIC
IGNITION SWITCH
SPRING LOADED ON / OFF SWITCH
VALVE CLEARANCE
SPARK PLUG GAP
0.020 INCH (0.5 mm)
LUBRICATION
SAE 10W-40 OIL
CRANKCASE OIL CAPACITY
1.7 FL OZ (50mL)
FUEL
PROPANE 16.4 OZ CANISTER
CARBURETOR
CHOKE-LESS, ALL POSITION
STARTER
AUTO REWIND
MUFFLER
BAFFLED WITH GUARD
THROTTLE
SAFETY LOCK WITH MANUAL SPRING RETURN
THROTTLE CONTROL
FINGER- TIP TRIGGER
MAX. AIR VELOCITY
*ALL SPECIFICATIONS ARE BASED ON THE LATEST PRODUCT INFORMATION AT THE TIME OF PRINTING.
WE RESERVE THE RIGHT TO MAKE CHANGES AT ANY TIME WITHOUT NOTICE.
0.003-0.006 in. (0.076-0.152 mm)
MAX. AIR VOLUME
150 MPH
370 cfm
