LEIF GUIDE | 9
WWW.LEIFTECH.COM/GUIDE
INSERT BATTERIES
TURN LEIF UPSIDE DOWN, WITH WEELS UP
REMOVE BATTERY COVER BY OPENING LOCK TABS
GENTLY PULL OUT 2 BATTERY CONNECTORS AND ENSURE
CONNECTORS AND VELCRO STRAPS ARE OUTSIDE OF THE
BATTERY COMPARTMENT
SLIDE BATTERY IN WITH ONE SIDE FIRST (THE SIDE FACING THE
LONG SIDE OF THE VELCRO STRAPS)
CENTER BATTERY IN COMPARTMENT AND CONNECT THE
VELCRO STRAPS
CONNECT AND HIDE THE POWER CONNECTORS TO THE
BATTERY CONNECTORS
REPLACE BATTERY COVER:
START BY INSERTING SIDE TABS,
FINISH BY PUSHING IN LOCK TABS
UNTIL YOU HEAR A “CLICK”
BATTERY PACK
1
2
2
1
4
55
2
3
4
5
6
5
BATTERY COVER
LOCK TABS
START HERE
FINISH HERE
VERY IMPORTANT!!
DO NOT PULL
BATTERY CABLES
WITH FORCE
SIDE TABS
5
LEIFTECH.COM/TRAINING
