LELY WELGER
AP 530 / 630 / 730 / 830 - P23
AP 730
1132.99.03.03 07.14 (Original manual)
Operator Manual

Table of Contents

Questions and Answers

  • B
    Barbara GilbertAug 18, 2025
    Why is the throwing reach too short on my LELY WELGER Accessories?
    • B
      Benjamin MillerAug 18, 2025
      Several factors can cause a short throwing reach: * Thrower belts too widely spaced: Reduce the spacing. * Thrower belts: Re-tension them. * V-belt slips: Re-tension the V-belts. * Oil level too low: Top up the oil level. * Control wrongly set: Reset it. * PTO speed too low: Increase it to 540 rpm. * Bales too heavy: Reduce bale weight, for example, by shortening bale length. * Thrower belts badly worn: Fit new thrower belts.
  • A
    antonio77Aug 20, 2025
    What to do if the main drive clutch is slipping on my LELY WELGER Accessories?
    • J
      Joy MccarthyAug 20, 2025
      If the main drive clutch is slipping, it could be due to: * The baler being overloaded: Drive slower and gather less material. * The slip-threshold torque being too low: Have the clutch adjusted.
  • A
    Ashley MortonAug 23, 2025
    What to do if pick-up stops on my LELY WELGER Accessories?
    • M
      Megan TaylorAug 23, 2025
      If the pick-up stops, it might be because: * It's overloaded by a blockage or the pick-up clutch is slipping: Remove the blockage, drive slower, and gather less material. * It's touching the ground or is set too low: Set the pick-up higher.
  • K
    Kenneth CostaAug 26, 2025
    How to fix a drive shaft wobbling on LELY WELGER Accessories?
    • D
      Diana MayAug 26, 2025
      A wobbling drive shaft can be caused by: * Negotiating tight bends: Disengage the PTO drive shaft in bends or use a wide-angle drive shaft. * The baler being incorrectly attached: Attach the baler correctly.
  • A
    Ashley ShafferAug 28, 2025
    What causes baling material clogged between pick-up and straw table in LELY WELGER Accessories?
    • R
      Rachel RiggsAug 28, 2025
      If baling material is clogged between the pick-up and straw table, the causes might be: * The baler is overloaded: Drive slower, gather less material. * Windguard tines are bent: Straighten the windguard tines.
  • A
    Anthony HenryAug 30, 2025
    Why is my LELY WELGER Accessories labouring and slowly getting worse?
    • J
      Jacqueline UnderwoodAug 30, 2025
      If the implement is labouring and slowly getting worse, consider these possibilities: * Damp baling material: Slacken the bale density. * Cutter blades blunt: Sharpen the blades. * Baling channel gummed up: Empty the baling channel and clean inside.
  • X
    xbondSep 2, 2025
    How to prevent curved bales with LELY WELGER Accessories?
    • A
      Amanda MendezSep 2, 2025
      Curved bales can result from: * Uneven compacting: Alter the packer quick adjustment or adjust the feeder tines. * Deflecting cross-feeder or packer respond continuously: Drive the tractor in the next lower gear.
  • M
    Mrs. Connie StephensSep 4, 2025
    Why is the knot OK, but the twine torn on my LELY WELGER Accessories?
    • B
      ballardtylerSep 4, 2025
      If the knot is okay but the twine is torn, it may be due to: * Twine tensioner too loose; after the knotting cycle, twine runs on over the nose of twine guide plate "a": Adjust the twine tensioner to 26 mm spring height. * Twine not held tight by twine flicker; during the knotting cycle, twine runs on over nose of twine guide plate,ā€a": Adjust twine flicker correctly.
  • Z
    zpachecoSep 6, 2025
    What to do if the thrower does not shift on my LELY WELGER Accessories?
    • M
      Matthew CantrellSep 7, 2025
      If the thrower does not shift, the cause may be: * A blown fuse: Change the fuse.
  • E
    Erin BenjaminSep 9, 2025
    What causes a short loop on my LELY WELGER Accessories?
    • J
      James BarrettSep 9, 2025
      A short loop can be caused by: * Spring ā€œc" too weakly tensioned, twine held too loosely by knotter: Tighten nut ā€eā€œ, adjust measurement D.

Summary

2 Safety

2.1 Safety Instructions

Emphasizes operator responsibility for safe machine operation and maintenance.

2.2 Safety Alert Symbols

Explains the meaning of danger, warning, caution, and note symbols used.

2.3.1 General Safety

Fundamental safety rules for operating and maintaining the baler.

2.3.4 Operating Safety

Crucial safety precautions to observe during machine operation.

2.4.2 Safety Decal Messages

Explains the meaning and purpose of each safety decal.

3 Operation

3.1 Operator positions at the machine

Identifies safe operator zones and danger areas during operation.

3.3.1 Start up

Procedures for safely starting and preparing the baler for use.

3.3.2 Coupling and uncoupling the baler to the tractor

Step-by-step guide for attaching and detaching the baler.

3.3.3 Coupling the hydraulic lines*

Instructions for connecting hydraulic hoses to the tractor.

3.3.4 Connect the drive shaft

3.3.8 Wire tying

3.3.9 Twine tying

3.3.10 Shutdown procedure

Safe steps to follow when stopping the machine.

3.3.11 Depressurize hydraulic system

3.4.1 Moving to working position

3.4.2 Moving to transport position

3.5 Operation instruction in the field

General operating guidelines for field use.

3.5.3 Adjusting the pick-up

3.5.4 Setting bale density

Procedure for adjusting the firmness of the bales.

3.5.5 Setting bale length

Method for adjusting the length of the produced bales.

3.5.6 Bale thrower P23*

3.5.7 Clearing blockages

Steps to safely resolve material blockages in the baler.

5 Maintenance and adjustments

5.2.2 Changing the transmission oil

5.2.3 Examining and adjusting the cutting mechanism

5.2.4 Examining and adjusting timing

Procedures for setting the timing of the packer and ram.

5.2.5 Timing the cross-feeder in relation to the packer

Ensuring correct timing for baler components.

5.2.6 Examining ram movement

5.2.7 Examining needle brake

5.2.8 Examine the main drive

Checking the dual clutch system and its torque settings.

5.2.9 Maintain and adjust tying unit

Procedures for maintaining and adjusting the knotter.

5.2.10 Freeing up the deflecting cross-feeder

5.2.11 Wire tying service and lubrication

5.2.12 Hydraulic System

5.2.13 Thrower belt tensioning

LELY WELGER P23 Specifications
