LELY LOTUS 460 - 6 Dismounting from the Tractor

6 DISMOUNTING FROM THE TRACTOR
- Block the trail type headstock / STABILO self steering
device (fig. 15).
The machine can be stored in either of two positions: folded
out or folded up. Storage in the folded-out position is
recommended.
• Storage in folded-out position.
- Adjust all wheel supports in the same position.
- Lower the machine onto the ground.
- Gently lower the lateral rotors by means of the hydraulic
valve.
- Lower the machine onto the ground by means of the
tractor hydraulics.
• Storage in folded-up position
- Adjust the wheel supports of the innermost rotors in the
closest position to the dish (fig. 16) thus ensuring the
most stable machine position.
- Place the machine on a hard and solid surface.
All other instructions for dismounting the machine from the
tractor are identical for both kinds of storage.
- Switch off the tractor engine. Disengage the PTO shaft
from the tractor PTO.
- Place the PTO shaft in the hook (fig. 17).
- Remove the pressure from the hydraulic system and
uncouple the hydraulic hose. Slide the dust cap onto the
plug.
- Remove the control cord for the locking hook from the
tractor cab.
- Set the two parking jacks of the headstock in the lowest
position.
- Screw in the top link until the parking jacks are on ground
level.
- Adjust the rear parking jack in the lowest possible position
(fig. 17).
- Disengage the top link from the machine.
- Uncouple the lower arms from the machine.
