- Convince yourself of the presence and undamaged condi-
tion of all safety decals on the machine (fig. 24).
A
(P/N 9.1170.0408.0)
B (P/N 9.1170.0407.6) -4x-
C
(P/N 9.1170.0410.2)
D (P/N 9.1170.0420.5)
E (P/N 9.1170.0125.4)
F (P/N 16.61.175)
- Check the gearbox for grease leakage
Grease to be renewed every 500 working hours for which
the cover at the rear side of the gearbox (fig. 25) has to be
removed. Contents: 0,25 kg/specification Shell Alvania
WR-0. When fitting the cover: apply fluid sealing material
(Loctite 574) to the gearbox rim and bolt holes.
35
24
B
CD
B
F
E
A
C
B
D
A
E
B
F
25
SHELL ALVANIA WR-0
0,25 kg
A
E
B
