Configuration
Power Analyzer NORMA 4000, NORMA 5000 31
EO1111G REV G
If you wish to configure all three current channels in this way,
press Set All.
All channels are now set to ON.
Save the settings with SAVE in the desired configuration.
To manually configure the range for I1, enter the range in ampere
or, if e.g. shunts are used, in volt.
First field in column Auto is highlighted.
Press Enter, select OFF and confirm with Enter.
Automatic range adjustment is now disabled.
Move the cursor to the value in column Range and press
Enter.
Select a value in ampere,
– or –
if you use a shunt, select a value in volt.
Note
When a value in volt is entered, automatic configuration (Auto) is
set to Off. Below Scale, option menu A/V is displayed.
Confirm with Enter.
The settings are shown in column Range. Off is displayed in
column Auto.
If you wish to configure all three current channels in this way,
press Set All.
Save the settings with SAVE in the desired configuration.
If you intend to use a shunt or a probe, you must adjust the scale
for the output of the measuring signal.
Note
The correct parameter settings are shown on the type plate of the
shunt or probe.
You can ...
- enter the transducer ratio (U over I) at the external current
meters and instruct the device to calculate the final scale
factor
or
- enter the scale factor at the current transducer so that the
final scale factor can be calculated.
The parameters of the formula must be entered as follows:
- scale factor x transducer ratio
whereby
- scale factor: generally "1.0000" (one)
- transducer ratio: current (in ampere) to voltage (in volt)
Manual range
adjustment
(Range)
Configure scale
