LEM PFM 15.2 - Technical Specifications

6
PFM 10.2 PFM 12.2 PFM 15.2 PFM 15.3 PFM 15.3XL
Hi
g
h 1" EWT™ driver
Mid 6" midran
g
e
Low 10" woofer 12" woofer 15" woofer 15" woofer 2 x 15" Woofer
POWER HANDLING
(EIA RS-426A)
W continuous
W peak
100
200
150
300
250
500
250
500
500
1000
IMPEDANCE
Ohms 8 8 4 / 8 4 / 8 4
PAS SI VE CROSSOVER
Hz
5 kHz
6 dB/oct.
5 kHz
6 dB/oct.
4 kHz
6 dB/oct.
0.8/ 5 kHz
12 / 6 dB/oct.
400 @ 6dB/ott.
2600 @ 12-18dB/ott.
CONNECTIONS (passive
versions)
2 x SPEAKON
(input + link)
CONSTRUCTION
DIMENSIONS
mm (WxHxD) 340x458x285 390x508x325 458x578x405 482x608x405 477x1052x430
WEIGHT (passive / active)
k
g
9 / 12 11.5 / 15.5 16.5 / 21.5 19.5 / 24.5 27
EIA OUTPUT POWER
(1kHz, max THD 1%)
W 100 150 250 250 + 80
INPUT SENSITIVITY
dB (V)
INPUT IMPEDANCE
kohms
ACTIVE CROSS OVER
Hz
2 kHz
18 dB/oct.
DISTORSION
%
CONTROLS
CONNECTIONS
POWER SUPPLY
SENSITIVITY (SPL 1W/1m)
dB 96 97 98 98 99
MAX SPL continuous
dB 113 116 119 121 123
MAX SPL peak
dB 116 119 122 127 126
FREQUENCY RESPONSE
Hz (-10dB) 60 - 20k 55 - 20k 48 - 20k 45 - 20k 46 - 17K
DISPERSION (OxV)
° 90 x 60 90 x 60 90 x 60 90 x 60 60 x 40
<0.02 (THD+Noise)
30 (balanced) - 15 (unbalanced)
SYSTEM SPECIFICATIONS
COMPONENTS
2 x JACK (input + link)
See label on the apparatus
2 x JACK (input + link)
Volume
0 (0.775V)
Niobium horn tweeter
LOUDSPEAKER SPECIFICATIONS
AMPLIFIER SPECIFICATIONS (active versions)
Chipboard covered with blue carpet
PFM 12.2MA PFM 15.2MA PFM 8MA PFM 15S PFM 18S
Hi
g
h
Mid 8" wideran
g
e
Low 12" woofer 15" Woofer 15" woofer 18" woofer
POWER HANDLING
(EIA RS-426A)
W continuous
W peak
150
200
250
500
100
200
350
700
350
700
IMPEDANCE
Ohms 88
PAS SI VE CROSSOVER
Hz
5 kHz
6 dB/oct.
4000
6 dB/oct.
230 Hz
12 / 6 dB/oct.
120 Hz
6 / 6 dB/oct.
CONNECTIONS (passive
versions)
CONSTRUCTION
DIMENSIONS
mm (WxHxD) 390x508x325 450x572x400 305x395x275 478x508x478 630x540x550
WEIGHT (passive / active)
k
g
15 21,5 11.5 19.5 / 24.5 28.5 / 35
EIA OUTPUT POWER
(1kHz, max THD 1%)
W 150 250 100 350 350
INPUT SENSITIVITY
dB (V)
INPUT IMPEDANCE
kohms
ACTIVE CROSSOVER
Hz
DISTORSION
%
CONTROLS
CONNECTIONS
POWER SUPPLY
SENSITIVITY (SPL 1W/1m)
dB 97 98 95 94 96
MAX SPL continuous
dB 116 119 114 118 120
MAX SPL peak
dB 119 122 117 121 123
FREQUENCY RESPONSE
Hz (-10dB) 55 - 20k 48 - 20k 65 - 20k 40 - 300 40-200
DISPERSION (OxV)
° 90 x 60 90 x 60 90 x 90
SYSTEM SPECIFICATIONS
See label on the apparatus
Volume - Shield on/off XOVER frequency
JACK + XLR-F (in)
JACK + XLR-M (out)
Volume
2 x JACK (input + link)
LOUDSPEAKER SPECIFICATIONS
AMPLIFIER SPECIFICATIONS (active versions)
3 x JACK
(input + link + out)
Niobium horn tweeter
COMPONENTS
0 (0.775V)
<0.02 (THD+Noise)
From 80 to 320
30 (balanced) - 15 (unbalanced)
5. Technical specifications
