LENCO DIR-200 User Manual

28
6.
6.
6.
6. Troubleshooting
Troubleshooting
Troubleshooting
Troubleshooting
Error
Error
Error
Error Remedy
Remedy
Remedy
Remedy
The device does
not switch on.
Check if the power adaptor is connected properly.
No sound. 1. Turn on the sound as it may be muted
2. Increase the volume.
3. Pull any connected headphone or speaker from
the connector sockets.
No network
connection can be
established.
1. Check the WLAN function.
2. Try to set an IP address at the device.
3. Activate the DHCP function on the router and
make the connection again at the device.
4. Check if the firewall is activated on the network
- set the respective program in such a way that
access is possible.
5. Reboot the router
WiFi connection
cannot be
established.
1. Check the availability of WLAN network on the
router.
2. Place the device closer to the router.
3. Make sure the password is correct.
No station is
found.
1. Check the network as well as the access point
and firewall.
2. The station may not be available currently, try
it again later or select another station.
3. The link of the station is changed or the station
no longer transmits - ask the provider for
information.
4. The link of manual added station is not correct,
make sure it is correct and re-enter.
Hiss in FM mode 1. Check/move the FM aerial.
2. Move the radio.

LENCO DIR-200 Specifications

General

Radio type	Internet
Tuner type	Analog & digital
PLL synthesizer	Yes
Supported radio bands	DAB+, FM
RMS rated power	14 W
Apple docking compatibility	Not supported
Total Harmonic Distortion (THD)	10 %
Display type	TFT
Display diagonal	2.8 \
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	-
Antenna type	External
Product color	Wood
Cables included	Audio (3.5mm)
Package weight	2400 g
Power source	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	18 W

Weight and Dimensions

Depth	140 mm
Width	300 mm
Height	120 mm
Weight	1800 g
