5
STANDBY
This device is provided with an automatic standby mode which is automatically activated after 20 minutes of non-use. In
standby mode, the power consumption of the turntable is reduced to less than 0.5 W to avoid unnecessary power
consumption. The standby mode will be interrupted automatically as soon as the speed selector is set to one of the two
speeds.
AUTO STOP
Auto stop, also known as auto shut off, uses a system to halt the record from spinning once it has finished playing or the
stylus doesn’t come into contact with the vinyl record for 5 minutes, rather than continuing to wear at the stylus.
Some assembly required before you can begin to use your new unit. Please follow the assembly instruction below before
attempting to use you new turntable.
Before you begin assembly please be sure all parts and accessories have arrived intact.
NOTES:
Do not connect the Power Adapter before assembly has been completed.
Before turning the power on, make sure once again all the connections. Always turn off the power when connecting
or disconnecting.
Read this manual carefully before using the unit. Be sure to store the manual in a safe place for future reference.
Attach a stylus cartridge to the HEADSHELL before assembling the turntable unit.
Headshell Assembly:
When installing a cartridge, refer to the operating instructions of that cartridge.
During installation, attach the stylus protector to guard the stylus tip from damage.
Connect the HEADSHELL lead wires to the cartridge terminals. The terminals of cartridges and the HEADSHELL lead wires
are color coded. Connect each lead wire to the cartridge terminals of the same color.
White (L+) ................................................ Left channel +
Blue (L-) .................................................... Left channel –
Red (R+) .................................................... Right channel +
Green (R-) ................................................. Right channel –
