3. Identification of Controls
Main Unit
5
1.SD/MMC
2. POWER ON/OFF
3. HEADPHONE OUT JACKS
4. VIDEO/AUDIO OUT
5. VIDEO/AUDIO IN
6.USB
7. DC OUT
8. DC IN 9-12V
9. ENTER
10. UP/DOWN/LEFT/RIGHT/VOL-/VOL+
11. SOURCE
12. UP/DOWN
13. MODE
Slaver TFT menu se
.
14. LEFT/ VOL-/RIGHT / VOL+
15.BACK LIGHT
Slaver TFT backlightswitch
16. POWER ON/OFF
17. AV IN
18. HEADPHONE OUT JACKS
19. DC IN
MASTER TFT SCREEN
SLAVER TFT SCREEN
1
2
3
4
5
6
7
8
9
10
11
16
17
18
19
15
12 13
14
