BALTIC R410A-IOM-0708-E Page 31
WITH OPTIONS
(Return and supply opening shown on this drawing do not apply to BAC/BAH with electric
heater or hot water coil )
BAC
BAH
035
1D Down supply air 3 Fresh air 5D Down hot water entry 8 Extraction
1F Front supply air 4F Front main power entry 9 Smoke outlet
2D Down return air 4D
Down main power
entry
71 Outdoor coil inlet 10 Condensate drainage
2F Front return air 5F Front hot water entry 70 Outdoor coil outlet
(*) Total Length (unit + option)
To Next Page
