ELECTRICAL – Outdoor Control (A175) Jumpers and Terminals
RAST TERMINALS FOR
THERMOSTAT WIRING
CONNECTION
PUSH BUTTON
7 SEGMENT
DISPLAY
PUMP DOWN – WHEN UNIT IS IN
PUMP DOWN MODE, Pd WILL BE
DISPLAYED ON 7-SEGMENT.
TO ACTIVATE PUMP DOWN MODE,
THE CONTROL MUST BE IN THE
IDLE STATE, AND THE PUMP DOWN
JUMPER PLACED ACROSS THE
TWO PUMP DOWN PINS.
TO DEACTIVATE, REMOVE JUMPER.
FIGURE 9
