• 14 • Installation - Operation - Maintenance manual (IOM) • AIR COOLED CHILLERS & SPLIT UNITS - 0105-E
H
2
2
H1
CONDENSING UNITS
Condensing unit
without capacity control
Condensing unit
with capacity control
H1
3
4
H2
2
2
H4
3
4
H4
H1 : 15 m. maxi
H2 : 5 m. maxi
H4 : 0,15 m. maxi
1 - Lower trap with single tube
2 - Clode coupled trap
3 - Lower trap with double tubes
4 - Higher trap with double tubes
Min 0,25% gradient
Min 0,25% gradient
If receiver option : PED declaration class 3
If no receiver option : PED declaration class 1
INSTALLATION - TRANSPORT - HANDLING
