Main screen Code Description Code Description Code Description Code Unit Min Factory Max
6-Comp.3 - Circ.2
2460
1-Config.
2461 Liste
2-State
2462 Liste
3-Sw State
2463 On/Off
4-Sw High P.
2464 On/Off
5-Sw Low P.
2465 On/Off
6-Relay
2466 On/Off
7-H.Pump
2467 On/Off
8-Bypass
2468 On/Off
9-Run Time
2469 h
5-EEV 2500 1-Circuit 1 2510 1-Config. 2511 Liste
2-State 2512 Liste
3-Position 2513 ~
2-Circuit 2 2520 1-Config. 2521 Liste
2-State 2522 Liste
3-Position 2523 ~
6-Ventilation 2600 1-Fan 1 - Circuit 1 2610 1-Config. 2611 Liste
2-State 2612 Liste
3-Sw State 2613 On/Off
4-Relay 2614 On/Off
5-Modulat. 2615 %
2-Fan 2 - Circuit 1 2620 1-Config. 2621 Liste
2-State 2622 Liste
3-Sw State 2623 On/Off
4-Relay 2624 On/Off
3-Fan 3 - Circuit 1 2630 1-Config. 2631 Liste
2-State 2632 Liste
3-Sw State 2633 On/Off
4-Relay 2634 On/Off
OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range CLIMATIC™ 50 - Menu Tree - ECOLOGIC rangeCLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range
CLIMATIC™ 50 - Menu Tree - ECOLOGIC range (continued)
