OPERATION -
CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX rangeCLIMATIC™ 50 - Menu Tree - ECOMAX range
CLIMATIC™ 50 - Menu Tree - ECOMAX range
Main screen Code Description Code Description Code Description Code Unit Min Factory Max
6-Comp.4
2460
1-Config.
2461 Liste
2-State
2462 Liste
3-Sw State
2463 On/Off
4-Sw High P.
2464 On/Off
5-Sw Low P.
2465 On/Off
6-Relay
2466 On/Off
7-Valve
2467 On/Off
8-Run Time
2468 h
5-EEV 2500 1-Circuit 1 2510 1-Config. 2511 Liste
2-State 2512 Liste
3-Position 2513 ~
2-Circuit 2 2520 1-Config. 2521 Liste
2-State 2522 Liste
3-Position 2523 ~
3-Circuit 1 2530 1-Config. 2531 Liste
2-State 2532 Liste
3-Position 2533 ~
4-Circuit 2 2540 1-Config. 2541 Liste
2-State 2542 Liste
3-Position 2543 ~
6-Ventilation 2600 1-Fan - Circuit 1 2610 1-Config. 2611 Liste
2-State 2612 Liste
3-Sw State 2613 On/Off
4-Relay 1 2614 On/Off
5-Relay 2. 2615 On/Off
6-Relay 3 2616 On/Off
7-Relay 4 2617 On/Off
8-Relay 5 2618 On/Off
9-Modulat. 2619 %
1-Fan - Circuit 2 2620 1-Config. 2621 Liste
2-State 2622 Liste
3-Sw State 2623 On/Off
4-Relay 1 2624 On/Off
5-Relay 2. 2625 On/Off
6-Relay 3 2626 On/Off
7-Relay 4 2627 On/Off
8-Relay 5 2628 On/Off
9-Modulat. 2619 %
