Page 10
BLOWER DATA
EL296UH070XV36B BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR WITH OPTIONAL RETURN AIR BASE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1070 1205
+18% 1020 1150
+12% 955 1100
+6% 895 1035
Factory Default 850 965
–6% 795 905
–12% 745 845
–18% 690 790
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 595 715 815 950 855 1045 1205 1350
Factory Default 520 655 755 840 790 945 1090 1255
– 490 595 670 745 720 845 985 1130
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH070XV36B BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 18 32 46 61 76 89 104 115 133 64 83 95 120 141 159 175 203 208 234 246
Med-low 34 52 69 86 104 126 141 160 174 109 131 150 179 204 219 239 268 283 313 335
Med-High 63 82 98 115 138 153 173 187 209 177 197 227 246 273 311 328 354 383 402 408
High 88 107 131 148 175 192 217 235 253 261 281 312 346 382 402 430 465 489 506 533
Factory Default
Cooling
Speed
Low 12 25 37 55 66 82 94 105 121 43 61 76 99 121 133 162 169 189 211 224
Med-low 25 40 55 74 89 109 120 136 150 76 96 112 138 162 186 207 232 243 262 281
Med-High 41 61 75 98 115 135 151 173 189 129 150 177 198 227 247 272 301 324 332 369
High 63 86 99 122 139 159 180 204 216 209 227 254 282 298 324 341 364 395 413 428
– Setting
Cooling
Speed
Low 9 20 35 48 59 75 86 94 110 29 43 63 84 99 113 131 144 164 185 197
Med-low 16 32 45 62 75 90 103 119 138 56 71 101 112 131 158 168 184 207 235 245
Med-High 28 43 63 77 98 115 132 145 162 88 107 129 154 183 204 214 245 263 281 308
High 46 61 86 100 121 136 153 172 193 142 163 187 216 236 261 279 301 325 356 375
