BLOWER DATA
EL296UH090XV36C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1215 1300
+18% 1140 1240
+12% 1100 1170
+6% 1020 1115
Factory Default 965 1070
–6% 915 970
–12% 850 925
–18% 805 855
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 625 710 830 950 875 1040 1210 1360
Factory Default 565 670 760 860 800 945 1100 1245
– 520 610 685 785 720 840 970 1115
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH090XV36C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 19 33 51 67 81 97 113 128 144 47 64 90 111 127 153 174 193 215 234 250
Med-low 35 52 76 90 108 130 146 166 185 87 114 130 158 184 205 227 252 278 301 321
Med-High 51 70 92 117 138 155 181 199 219 146 170 199 223 246 277 303 329 357 379 399
High 69 94 113 133 152 177 194 222 246 225 250 277 308 329 362 391 411 442 465 489
Factory Default
Cooling
Speed
Low 14 31 44 59 75 88 104 125 137 37 54 74 94 114 135 152 175 187 209 223
Med-low 29 46 63 80 95 114 133 146 164 65 87 108 130 152 173 196 222 236 262 283
Med-High 39 56 78 97 117 137 155 175 192 102 127 152 175 202 228 246 279 306 328 345
High 46 68 86 111 126 154 174 194 214 167 184 218 253 272 301 332 360 381 402 421
– Setting
Cooling
Speed
Low 11 27 39 57 70 84 99 113 131 26 45 61 81 96 118 134 152 169 189 205
Med-low 23 39 53 71 87 103 118 133 148 44 60 85 107 127 150 169 186 207 226 247
Med-High 24 43 56 79 97 111 129 149 165 75 101 117 140 160 182 215 235 255 275 296
High 33 51 69 94 111 131 150 170 186 112 134 160 186 220 236 264 293 311 335 363
