BLOWER DATA
EL296UH090XV36C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR WITH OPTIONAL RETURN AIR BASE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1170 1250
+18% 1110 1200
+12% 1045 1145
+6% 995 1070
Factory Default 940 1010
–6% 880 950
–12% 815 895
–18% 775 825
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 715 810 930 850 995 1165 1305
Factory Default 570 660 735 820 775 905 1050 1205
– 530 600 670 725 710 800 945 1070
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH090XV36C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 12 29 43 59 75 92 111 123 139 41 62 86 102 123 145 165 185 205 229 253
Med-low 24 42 61 76 97 112 132 150 169 79 108 126 148 174 190 218 248 273 294 316
Med-High 38 56 81 99 115 138 157 176 199 131 152 184 208 237 264 289 320 339 361 390
High 61 85 104 127 144 171 192 212 239 205 226 258 283 312 344 365 393 410 437 466
Factory Default
Cooling
Speed
Low 9 26 37 54 67 83 97 112 130 30 50 72 87 108 127 149 167 184 209 226
Med-low 19 37 53 67 83 101 119 135 153 62 86 101 129 144 165 189 215 232 251 275
Med-High 27 48 65 82 101 119 139 161 177 91 114 140 163 195 220 239 265 289 315 339
High 42 62 85 99 121 143 162 183 203 149 167 201 228 258 289 316 333 355 389 403
– Setting
Cooling
Speed
Low 8 23 35 51 62 77 91 104 119 25 45 61 75 91 112 131 147 166 184 198
Med-low 13 29 46 60 78 93 110 125 140 40 61 81 103 119 143 162 179 204 220 245
Med-High 22 41 57 70 88 109 127 144 159 70 92 120 133 165 178 203 231 246 274 301
High 29 50 69 83 106 123 143 164 183 101 124 151 180 203 227 257 276 306 326 358
