BLOWER DATA
EL296UH045XV36B BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 910 1125
+18% 850 1080
+12% 785 1035
+6% 765 990
Factory Default 755 935
–6% 690 880
–12% 635 810
–18% 600 765
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 610 760 845 975 920 1065 1205 1340
Factory Default 550 680 770 880 815 985 1110 1245
– 465 610 720 775 745 890 1020 1130
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH045XV36B BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 19 37 57 74 97 116 136 151 168 55 82 104 135 158 194 221 243 270 297 314
Med-low 34 57 80 103 124 148 168 195 216 103 123 159 193 225 254 282 307 338 361 389
Med-High 45 74 98 123 150 179 204 236 260 164 198 225 260 287 326 352 391 428 450 478
High 76 103 133 163 191 223 256 277 303 235 256 294 346 374 409 445 478 510 541 551
Factory Default
Cooling
Speed
Low 16 31 52 67 85 100 118 136 150 38 68 90 106 133 162 188 212 239 262 286
Med-low 20 45 65 85 110 125 145 170 195 75 99 128 159 187 219 251 273 299 323 350
Med-High 38 64 88 106 130 157 180 207 230 125 145 186 216 248 278 303 331 365 388 419
High 51 81 103 133 157 191 218 242 268 182 210 245 273 317 346 376 410 440 465 497
– Setting
Cooling
Speed
Low 10 28 40 59 73 89 105 121 138 30 52 72 100 119 141 159 185 206 228 253
Med-low 20 38 58 75 97 116 136 151 169 48 75 99 124 151 180 205 237 261 285 303
Med-High 27 48 69 93 116 133 152 178 203 85 107 139 172 201 233 266 286 312 337 364
High 38 66 89 106 131 159 184 209 235 134 155 196 223 259 290 316 344 374 399 432
