BLOWER DATA
EL296UH045XV36B BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR WITH OPTIONAL RETURN AIR BASE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 895 1115
+18% 850 1070
+12% 795 1030
+6% 755 980
Factory Default 715 920
–6% 665 850
–12% 645 805
–18% 595 740
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 730 845 965 895 1060 1185 1345
Factory Default 550 660 760 875 820 975 1105 1215
– 490 610 685 770 720 860 1015 1125
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH045XV36B BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 20 36 57 77 99 111 133 149 168 54 82 99 130 157 180 210 238 259 282 308
Med-low 28 50 72 97 118 141 161 184 207 103 122 159 189 220 250 277 303 331 353 382
Med-High 45 74 94 121 148 170 201 221 254 162 188 227 259 283 318 353 383 414 435 473
High 73 98 130 157 186 219 247 274 294 224 249 283 326 366 398 433 473 491 529 545
Factory Default
Cooling
Speed
Low 14 32 47 62 82 100 119 132 149 38 63 82 109 131 161 176 210 231 250 272
Med-low 20 40 60 80 105 120 145 160 180 74 96 125 152 182 214 242 268 289 313 335
Med-High 31 57 76 104 126 153 170 196 223 123 143 180 215 240 272 300 326 359 379 408
High 51 81 98 128 156 178 208 235 258 173 206 240 261 297 337 365 402 431 456 490
– Setting
Cooling
Speed
Low 8 27 38 54 73 88 106 119 137 27 46 71 92 112 133 155 178 195 214 242
Med-low 21 37 57 77 100 112 134 149 169 48 75 95 122 149 171 201 222 255 271 294
Med-High 25 44 67 86 110 127 150 170 187 84 105 139 167 197 229 256 284 305 330 355
High 34 60 79 106 128 157 173 203 227 130 153 188 225 248 282 307 339 371 392 420
