Page 8
BLOWER DATA
EL296UH070XV36B BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1095 1220
+18% 1035 1170
+12% 985 1120
+6% 915 1055
Factory Default 850 995
–6% 835 915
–12% 755 845
–18% 695 810
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 600 740 840 970 860 1060 1215 1365
Factory Default 555 665 770 855 810 960 1130 1265
500 600 680 790 705 840 1005 1140
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
EL296UH070XV36B BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 22 36 51 60 80 95 101 117 138 68 88 105 129 152 169 198 214 231 244 274
Med-low 37 57 75 89 106 127 148 168 182 121 144 168 192 211 243 262 287 305 329 358
Med-High 62 85 97 122 144 164 180 203 220 213 231 259 285 311 328 357 374 397 419 445
High 88 115 132 155 176 203 233 240 274 304 322 359 379 411 442 458 486 502 527 554
Factory Default
Cooling
Speed
Low 16 29 42 55 71 82 98 112 120 52 69 86 107 122 146 165 183 199 212 229
Med-low 26 41 63 79 88 112 128 145 159 89 108 135 151 174 198 223 247 268 288 298
Med-High 39 62 77 96 117 140 156 180 196 151 173 201 225 243 266 289 313 339 368 383
High 65 84 104 125 148 166 178 206 225 237 256 284 303 328 343 374 395 421 435 454
– Setting
Cooling
Speed
Low 11 21 35 53 64 75 82 95 113 34 50 67 86 106 121 141 159 174 186 201
Med-low 21 36 51 66 81 92 107 127 141 64 85 100 114 145 160 182 206 219 237 251
Med-High 35 48 66 82 104 118 137 146 159 101 125 143 171 193 211 242 258 282 304 330
High 43 60 82 100 123 144 159 174 197 161 188 211 229 258 277 307 327 354 379 404
