BLOWER DATA
EL296UH110XV48C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1480 1580
+18% 1410 1505
+12% 1330 1415
+6% 1255 1365
Factory Default 1190 1270
–6% 1130 1205
–12% 1070 1120
–18% 1020 1060
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 795 975 1065 1200 1085 1295 1515 1695
Factory Default 755 855 1000 1110 1015 1180 1375 1565
700 785 885 1025 920 1070 1235 1395
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 380 cfm.
EL296UH110XV48C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 35 58 79 99 120 148 166 192 209 79 107 142 168 196 225 254 286 314 344 376
Med-low 52 81 103 132 153 178 212 236 262 130 167 199 237 272 313 350 392 419 457 486
Med-High 93 128 156 183 207 246 274 314 339 215 246 290 334 375 416 457 490 528 569 598
High 108 144 175 207 241 276 308 345 376 287 333 383 427 482 515 571 614 666 716 756
Factory Default
Cooling
Speed
Low 28 49 69 92 110 128 147 175 192 63 88 122 143 169 198 224 250 281 311 330
Med-low 40 65 85 110 135 155 180 205 235 100 136 166 195 227 261 291 329 358 394 423
Med-High 59 85 115 139 163 190 220 245 274 154 192 229 270 309 345 383 428 459 503 534
High 85 116 148 175 201 235 263 299 325 245 280 328 370 412 444 488 521 570 608 650
– Setting
Cooling
Speed
Low 25 42 60 82 103 113 137 152 173 46 72 94 120 146 170 197 226 249 268 293
Med-low 39 62 82 102 120 140 165 187 207 74 99 137 162 193 218 247 276 305 337 366
Med-High 43 71 92 116 142 165 190 217 243 113 150 181 214 247 286 320 358 388 425 451
High 65 89 125 146 173 201 227 254 285 164 202 244 285 315 356 398 441 476 518 550
