Lennox EL296UHVX Series User Manual

Page 25
BLOWER DATA
EL296UH135XV60D BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR − Air volumes in bold require Optional Return Air Base and eld fabricated transition to accommodate
20 x 25 x 1 in. air lter in order to maintain proper air velocity.
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1725 2070
+18% 1635 1975
+12% 1555 1900
+6% 1470 1815
Factory Default 1405 1715
–6% 1325 1610
–12% 1250 1525
–18% 1185 1420
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1130 1275 1405 1555 1595 1805 1975 2180
Factory Default 1040 1185 1280 1415 1450 1625 1840 2000
– 950 1080 1185 1300 1310 1480 1655 1840
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296UH135XV60D BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 87 123 145 178 213 241 270 299 340 244 283 316 356 418 453 491 529 570 598 642
Med-low 131 161 197 228 266 309 334 361 392 340 377 425 477 528 570 615 661 702 732 789
Med-High 168 201 248 283 319 357 385 438 468 479 523 587 615 665 717 762 812 860 907 955
High 239 283 316 356 418 453 491 529 570 661 703 770 822 862 941 994 1037 1098 1136 1177
Factory Default
Cooling
Speed
Low 67 97 126 150 177 210 239 264 296 162 201 243 273 311 353 384 426 469 505 541
Med-low 100 130 165 190 225 255 290 320 350 245 281 322 374 433 465 509 546 596 629 666
Med-High 132 169 198 228 267 306 333 370 401 370 404 458 516 559 600 657 696 746 783 816
High 163 201 243 273 311 353 384 426 469 502 544 601 639 683 744 791 845 884 927 961
– Setting
Cooling
Speed
Low 57 84 107 133 157 177 206 236 259 126 158 192 226 265 290 326 360 392 424 459
Med-low 73 102 132 158 185 221 252 273 302 175 213 252 291 338 366 417 453 487 521 572
Med-High 100 130 167 193 225 257 290 320 354 254 292 343 377 431 475 521 566 604 642 678
High 126 158 192 226 265 290 326 360 392 370 404 458 516 559 600 657 696 746 783 816
