BLOWER DATA
EL296UH135XV60D BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1770 2125
+18% 1680 2015
+12% 1610 1935
+6% 1485 1855
Factory Default 1440 1740
–6% 1360 1650
–12% 1285 1565
–18% 1215 1460
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1150 1310 1440 1610 1640 1840 2000 2250
Factory Default 1080 1210 1330 1475 1480 1660 1885 2035
– 985 1095 1210 1315 1330 1500 1675 1885
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296UH135XV60D BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 79 108 140 173 200 232 265 290 325 229 250 310 367 396 452 487 529 557 595 639
Med-low 125 157 190 221 264 297 325 355 390 348 385 434 482 532 571 627 655 704 736 793
Med-High 162 199 241 268 303 350 390 426 454 505 532 597 649 689 733 782 826 872 906 942
High 222 250 310 367 396 452 487 529 557 696 733 780 839 910 974 996 1049 1091 1138 1175
Factory Default
Cooling
Speed
Low 63 93 119 144 173 199 230 258 284 172 210 249 277 326 361 394 444 467 513 545
Med-low 85 115 150 190 210 245 275 310 340 238 261 329 375 427 465 505 548 589 631 670
Med-High 125 159 190 222 260 295 325 358 391 392 426 482 518 581 619 665 699 741 789 826
High 172 210 249 277 326 361 394 444 467 523 561 612 671 716 751 805 867 899 935 986
– Setting
Cooling
Speed
Low 52 78 106 129 148 177 201 228 258 123 154 191 216 261 296 331 353 384 421 459
Med-low 68 98 124 150 184 207 241 268 294 172 214 244 289 334 368 408 454 491 523 564
Med-High 89 119 150 192 213 246 279 312 340 265 297 352 403 439 489 534 574 605 651 699
High 123 154 191 216 261 296 331 353 384 392 426 482 518 581 619 665 699 741 789 826
