BLOWER DATA
EL296UH110XV60C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR − Air volumes in bold require Optional Return Air Base and eld fabricated transition to accommodate
20 x 25 x 1 in. air lter in order to maintain proper air velocity.
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1495 1910
+18% 1425 1840
+12% 1335 1785
+6% 1210 1710
Factory Default 1195 1555
–6% 1140 1510
–12% 1075 1410
–18% 975 1300
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1050 1195 1315 1495 1515 1710 1870 2065
Factory Default 960 1095 1220 1355 1360 1555 1755 1890
– 850 985 1095 1220 1215 1400 1555 1755
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296UH110XV60C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 67 95 124 148 172 212 241 260 287 215 247 287 338 378 412 448 497 535 557 600
Med-low 112 140 176 200 232 262 303 323 350 332 360 420 459 500 551 601 636 666 705 747
Med-High 151 191 221 251 283 321 356 392 431 478 513 560 611 672 701 750 801 843 865 916
High 215 247 287 338 378 412 448 497 535 661 699 751 813 856 901 955 1005 1047 1088 1131
Factory Default
Cooling
Speed
Low 53 82 99 128 153 172 199 231 251 156 198 217 270 297 328 371 403 440 474 515
Med-low 81 109 136 165 198 229 259 281 307 244 272 327 361 410 446 494 527 564 600 636
Med-High 113 144 174 209 233 269 304 323 362 387 415 458 513 552 602 644 680 719 763 807
High 156 198 217 270 297 328 371 403 440 505 541 594 624 675 727 780 812 843 886 925
– Setting
Cooling
Speed
Low 43 62 84 111 125 152 167 189 211 114 137 183 206 235 264 303 330 358 388 417
Med-low 62 86 115 134 162 187 219 238 262 165 199 236 281 308 357 381 426 466 492 531
Med-High 81 109 136 165 198 229 259 281 307 239 269 326 354 413 463 498 523 573 601 656
High 114 137 183 206 235 264 303 330 358 387 415 458 513 552 602 644 680 719 744 776
