BLOWER DATA
EL296UH110XV60C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1385 1965
+18% 1475 1880
+12% 1355 1790
+6% 1370 1725
Factory Default 1200 1630
–6% 1140 1550
–12% 1070 1460
–18% 980 1345
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1060 1245 1345 1545 1560 1740 1930 2125
Factory Default 970 1145 1265 1395 1405 1565 1775 1945
– 885 1025 1110 1250 1270 1425 1610 1770
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296UH110XV60C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 81 113 135 165 200 228 251 280 315 220 254 300 346 385 432 472 511 560 600 610
Med-low 119 147 179 210 241 273 309 331 358 345 386 414 475 516 547 594 637 681 714 748
Med-High 157 191 225 265 304 331 377 405 435 492 536 573 623 666 711 761 804 842 891 918
High 220 254 300 346 385 432 472 511 560 675 699 767 839 876 915 973 1033 1062 1115 1134
Factory Default
Cooling
Speed
Low 60 88 114 137 167 187 219 244 276 163 196 231 266 309 348 388 421 451 489 512
Med-low 81 108 147 173 195 231 257 288 326 232 263 314 353 412 445 490 516 557 596 649
Med-High 122 145 182 215 246 286 306 333 360 372 401 449 498 541 577 643 672 695 744 765
High 163 196 231 266 309 348 388 421 451 497 539 579 646 681 734 773 817 851 904 957
– Setting
Cooling
Speed
Low 45 62 96 116 132 153 179 199 227 124 146 189 215 245 279 316 331 373 396 423
Med-low 56 85 115 134 159 185 215 251 270 163 195 243 270 314 353 397 414 470 496 535
Med-High 80 114 141 161 203 230 256 294 318 248 274 324 386 416 470 494 539 583 620 652
High 124 146 189 215 245 279 316 331 373 377 413 457 502 548 583 629 684 705 753 783
