Page 11
Unit Control Box Components Arrangement
ELS072/090S
ELS120S
ELS120D/ELS150D
ELS180D / ELS240D
TRANSFORMER
TRANSFORMER
TRANSFORMER
TRANSFORMER
CONTACTOR
CONTACTOR
ICM CONTROLLER
(FIELD INSTALLED)
ICM CONTROLLER
(FIELD INSTALLED)
ICM CONTROLLER
(FIELD INSTALLED)
ICM CONTROLLER
(FIELD INSTALLED)
