Page 8
BLOWER DATA
G40UH−60C−110−1, −2, −3 with 3/4 hp motor PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return
Air Base, Return Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2450 1155 1220 2300 1085 1060 2056 970 905 1725 815 735
0.05 12 2410 1135 1205 2265 1070 1045 2040 965 895 1715 810 725
0.10 25 2370 1120 1195 2230 1050 1030 2020 955 890 1710 810 720
0.15 37 2325 1095 1175 2200 1040 1015 1995 940 875 1700 800 715
0.20 50 2280 1075 1165 2170 1025 1005 1975 935 870 1695 800 710
0.25 62 2245 1060 1150 2130 1005 990 1950 920 855 1680 795 705
0.30 75 2205 1040 1135 2095 990 975 1925 910 845 1665 785 700
0.40 100 2115 995 1105 2010 950 940 1860 875 820 1625 770 685
0.50 125 2025 955 1060 1945 920 920 1810 855 805 1605 755 675
0.60 150 1910 900 1015 1850 875 885 1715 810 780 1540 730 670
0.70 175 1835 865 1005 1775 840 865 1655 780 765 1495 705 655
0.80 200 1745 825 975 1655 780 835 1540 725 730 1400 660 635
0.90 225 1610 760 945 1540 725 805 1475 695 715 1310 620 615
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G40UH−60C−110−1, −2, −3 with 3/4 hp motor PERFORMANCE − Single Side Return Air − Air volumes in bold require field fab-
ricated transition to accommodate 20 x 25 x 1 in. (508 x 635 x25 mm) cleanable air filter in order to maintain proper air
velocity.
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2395 1130 1230 2260 1065 1085 2015 950 920 1730 815 750
0.05 12 2365 1115 1220 2230 1050 1070 1985 935 905 1720 810 745
0.10 25 2330 1100 1205 2200 1040 1060 1960 925 890 1705 805 750
0.15 37 2285 1080 1190 2170 1025 1045 1030 485 880 1695 800 740
0.20 50 2245 1060 1170 2135 1010 1030 1905 900 870 1675 790 735
0.25 62 2200 1040 1160 2100 990 1020 1890 890 860 1665 785 730
0.30 75 2170 1025 1145 2070 980 1005 1870 880 850 1655 780 720
0.40 100 2085 985 1110 1990 940 975 1825 860 835 1610 760 705
0.50 125 1980 935 1075 1910 900 945 1755 830 810 1555 735 690
0.60 150 1890 890 1045 1835 865 915 1670 790 780 1515 715 680
0.70 175 1800 850 1020 1725 815 885 1615 760 770 1445 685 655
0.80 200 1700 805 995 1645 775 855 1525 720 745 1380 650 645
0.90 225 1590 750 980 1520 720 820 1410 665 710 1300 615 625
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
