Page 9
BLOWER DATA
G40UH−60C−110 with 1 hp motor PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air
Base, Return Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Different Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2655 1250 1407 2370 1120 1063 2085 985 894 1665 785 679
.10 25 2580 1215 1376 2350 1110 1043 2065 975 875 1650 780 667
.20 50 2500 1180 1346 2305 1085 1012 2045 965 849 1645 775 662
.30 75 2410 1135 1305 2230 1050 978 2010 950 820 1640 775 649
.40 100 2320 1095 1270 2165 1020 947 1940 915 786 1625 765 634
.50 125 2225 1050 1235 2090 985 914 1895 895 763 1610 760 622
.60 150 2130 1005 1205 2000 945 880 1840 870 740 1570 740 603
.70 175 2030 955 1155 1915 905 851 1760 830 709 1535 725 590
.80 200 1925 910 1123 1820 860 823 1670 790 681 1475 695 566
.90 225 1795 845 1078 1690 795 788 1560 735 655 1395 660 537
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G40UH−60C−110 with 1 hp motor PERFORMANCE − Single Side Return Air − Air volumes in bold require field fabricated
transition to accommodate 20 x 25 x 1 in. (508 x 635 x 25 mm) cleanable air filter in order to maintain proper air velocity.
External Static
Air Volume / Watts at Different Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2430 1145 1309 2245 1060 1006 1910 900 843 1635 770 686
.10 25 2355 1110 1277 2190 1035 978 1905 900 817 1620 765 677
.20 50 2280 1075 1242 2140 1010 950 1885 890 797 1610 760 667
.30 75 2205 1040 1218 2075 980 924 1860 875 782 1605 755 655
.40 100 2130 1005 1189 2005 945 905 1815 855 752 1595 750 636
.50 125 2045 965 1159 1920 905 864 1750 825 726 1565 740 619
.60 150 1955 920 1132 1850 875 840 1700 800 705 1525 720 605
.70 175 1860 875 1105 1760 830 817 1610 760 674 1475 700 582
.80 200 1755 830 1067 1670 790 789 1540 725 654 1395 660 560
.90 225 1645 775 1033 1575 745 763 1445 680 627 1325 625 540
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
