Page 29
G50UH Series
Electronic Ignition
The SureLight
®
integrated control has an added feature of
an internal Watchguard control. The feature serves as an
automatic reset device for ignition control lockout caused
by ignition failure. After one hour of continuous thermostat
demand for heat, the Watchguard will break and remake
thermostat demand to the furnace and automatically reset
the control to begin the ignition sequence.
Flue And Chimney
1 − Check flue pipe, chimney and all connections for tight-
ness and to make sure there is no blockage.
2 − Check unit for proper draft.
3 − Is pressure switch closed? Obstructed flue will cause
unit to shut off at pressure switch. Check flue and outlet
for blockages.
4 − Reset manual flame rollout switches on burner box
cover.
Failure To Operate
If the unit fails to operate, check the following:
1 − Is the thermostat calling for heat?
2 − Are access panels securely in place?
3 − Is the main disconnect switch closed?
4 − Is there a blown fuse?
5 − Is the filter dirty or plugged? Dirty or plugged filters will
cause the limit control to shut the unit off.
6 − Is gas turned on at the meter?
7 − Is the manual main shut-off valve open?
8 − Is the internal manual shut-off valve open?
9 − Is the unit ignition system in lock out? If the unit locks
out again, inspect the unit for blockages.
Blower Performance Data
NOTES − All air data is measured external to unit with 1 in. cleanable filter (not furnished − field provided) in place.
Air volume based on bottom air return air. Actual air volume may vary on side return air applications.
G50UH−24A−045 PERFORMANCE
External
Air Volume / Watts at Various Blower Speeds
Static
in. w.g.
cfm
Watts cfm Watts cfm Watts
0.00
1090 460 905 390 725 300
0.10 1065 445 895 385 710 295
0.20 1030
425 890 375 690 290
0.30
995 410 860 365 665 280
0.40 960 395 840 350 650 270
0.50 910
380 795 335 610 260
0.60
840 355 750 315 540 245
0.70 770 340 665 295 490 235
0.80 660
315 555 275 420 225
0.90
560 295 480 260 355 210
G50UH−24A−070 PERFORMANCE
External
Air Volume / Watts at Various Blower Speeds
Static
in. w.g.
cfm
Watts cfm Watts cfm Watts
0.00
1075 445 905 375 730 290
0.10 1065 440 895 370 720 285
0.20 1055
430 885 360 710 280
0.30
1030 415 875 355 690 270
0.40 1010 400 860 350 675 270
0.50 975
390 840 340 660 265
0.60
940 375 805 325 640 255
0.70 890 360 755 305 605 240
0.80 830
340 700 285 565 225
0.90
765 305 640 265 515 205
G50UH−36A−070 PERFORMANCE
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
in. w.g.
cfm
Watts cfm Watts cfm Watts cfm Watts
0.00
1500 705 1290 565 985 455 830 375
0.10 1450 680 1255 545 970 440 810 360
0.20 1400
655 1225 525 955 425 795 350
0.30
1340 630 1180 500 930 405 780 335
0.40 1285 610 1140 475 900 390 745 325
0.50 1215
580 1080 450 865 375 705 310
0.60
1150 560 1015 430 810 355 655 290
0.70 1060 535 940 405 730 330 585 270
0.80 955
515 800 370 655 305 480 260
0.90
785 475 605 325 585 270 410 255
G50UH−36B−090 PERFORMANCE
Air Volume / Watts at Various Blower Speeds
High
Medium−
High
Medium−
Low
Low
in. w.g.
cfm
Watts cfm Watts cfm Watts cfm Watts
0.00
1500 720 1255 595 1040 460 900 370
0.10 1465 685 1240 570 1035 445 890 360
0.20 1435
660 1225 545 1030 435 880 350
0.30
1400 630 1200 520 1020 415 870 340
0.40 1345 595 1170 495 1000 400 855 330
0.50 1300
575 1135 475 965 380 830 300
0.60
1235 545 1080 445 930 360 780 290
0.70 1165 510 1020 415 870 340 740 280
0.80 1080
480 940 385 800 315 670 260
0.90
985 445 840 355 710 290 600 245
