Page 32
505254M 05/2009
NOTES − All air data is measured external to unit with 1 in. cleanable filter (not furnished − field provided) in place.
G50UH−60D−155 PERFORMANCE
Air Volume / Watts at Different Blower Speeds
External
Static
Pressure
Bottom Return Air, Side Return Air with Optional RAB
Return Air Base, Return Air from Both Sides or Return
Air from Bottom and One Side.
Single Side Return Air − Air volumes in bold require field
fabricated transition to accommodate 20 x 25 x 1 in. air
filter in order to maintain proper air velocity.
in. w.g.
High
Medium−High Medium−Low Low High Medium−High Medium−Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
.00 2670 1386 2325 1048 1970 857 1700 706 2410 1282 2175 987 1870 833 1620 675
.10 2580 1342 2320 1045 1965 842 1690 696 2335 1257 2140 956 1860 810 1610 667
.20 2510
1311 2255 985 1960 817 1640 662 2255 1225 2085 918 1855 788 1605 658
.30
2425 1277 2210 953 1955 803 1635 649 2205 1200 2025 896 1830 764 1600 647
.40 2345 1246 2150 922 1925 778 1630 633 2120 1164 1975 874 1795 742 1595 628
.50 2255
1217 2095 897 1890 752 1615 618 2040 1131 1905 847 1745 731 1575 618
.60
2170 1182 2010 863 1840 733 1590 605 1955 1103 1835 820 1695 698 1540 601
.70 2090 1139 1925 833 1785 708 1550 588 1870 1069 1760 792 1635 673 1465 568
.80 1895
1106 1840 806 1710 683 1500 571 1770 1041 1670 763 1560 646 1415 548
.90
1855 1064 1740 776 1620 655 1430 551 1660 1006 1585 740 1480 629 1345 527
