Page 11
BLOWER DATA
G50UH−60C−110 PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Return Air
from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Different Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2655 1250 1407 2370 1120 1063 2085 985 894 1665 785 679
.10 25 2580 1215 1376 2350 1110 1043 2065 975 875 1650 780 667
.20 50 2500 1180 1346 2305 1085 1012 2045 965 849 1645 775 662
.30 75 2410 1135 1305 2230 1050 978 2010 950 820 1640 775 649
.40 100 2320 1095 1270 2165 1020 947 1940 915 786 1625 765 634
.50 125 2225 1050 1235 2090 985 914 1895 895 763 1610 760 622
.60 150 2130 1005 1205 2000 945 880 1840 870 740 1570 740 603
.70 175 2030 955 1155 1915 905 851 1760 830 709 1535 725 590
.80 200 1925 910 1123 1820 860 823 1670 790 681 1475 695 566
.90 225 1795 845 1078 1690 795 788 1560 735 655 1395 660 537
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G50UH−60C−110 PERFORMANCE − Single Side Return Air − Air volumes in bold require field fabricated transition to accom-
modate 20 x 25 x 1 in. (508 x 635 x25 mm) cleanable air filter in order to maintain proper air velocity.
External Static
Air Volume / Watts at Different Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2430 1145 1309 2245 1060 1006 1910 900 843 1635 770 686
.10 25 2355 1110 1277 2190 1035 978 1905 900 817 1620 765 677
.20 50 2280 1075 1242 2140 1010 950 1885 890 797 1610 760 667
.30 75 2205 1040 1218 2075 980 924 1860 875 782 1605 755 655
.40 100 2130 1005 1189 2005 945 905 1815 855 752 1595 750 636
.50 125 2045 965 1159 1920 905 864 1750 825 726 1565 740 619
.60 150 1955 920 1132 1850 875 840 1700 800 705 1525 720 605
.70 175 1860 875 1105 1760 830 817 1610 760 674 1475 700 582
.80 200 1755 830 1067 1670 790 789 1540 725 654 1395 660 560
.90 225 1645 775 1033 1575 745 763 1445 680 627 1325 625 540
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G50UH−60D−135−1, −2, −3 PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Return
Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2465 1165 1205 2325 1100 1060 2155 1015 930 1895 895 780
0.05 12 2430 1145 1195 2295 1085 1050 2125 1000 920 1875 885 770
0.10 25 2395 1130 1180 2265 1070 1040 2095 990 910 1855 875 765
0.15 37 2350 1110 1165 2230 1050 1025 2070 975 900 1830 865 755
0.20 50 2310 1090 1150 2195 1035 1010 2045 965 890 1805 850 745
0.25 62 2265 1070 1135 2155 1015 995 2010 950 875 1785 840 735
0.30 75 2220 1050 1120 2115 1000 980 1975 930 865 1765 830 730
0.40 100 2120 1000 1080 2035 960 950 1915 905 845 1715 810 720
0.50 125 2050 970 1055 1955 925 925 1830 865 815 1645 775 700
0.60 150 1930 910 1015 1860 880 895 1745 825 795 1585 745 680
0.70 175 1835 865 985 1775 840 870 1655 780 770 1530 720 670
0.80 200 1720 810 955 1645 775 830 1560 735 745 1445 685 650
0.90 225 1595 755 925 1535 725 800 1455 685 720 1310 620 620
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
