Page 13
BLOWER DATA
G50UH−60D−155−1, −2, −3 PERFORMANCE − Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Return
Air from Both Sides or Return Air from Bottom and One Side.
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2380 1120 1135 2235 1055 1000 2060 970 875 1875 885 750
0.05 12 2340 1105 1130 2205 1040 990 2035 960 865 1840 870 745
0.10 25 2305 1090 1125 2180 1030 975 2015 950 855 1810 855 735
0.15 37 2265 1070 1105 2145 1010 960 1990 940 845 1790 845 725
0.20 50 2220 1045 1090 2105 995 945 1960 925 835 1765 835 720
0.25 62 2180 1030 1075 2080 980 935 1935 910 825 1740 820 710
0.30 75 2145 1010 1065 2050 965 925 1905 900 815 1715 810 700
0.40 100 2060 970 1040 1975 930 900 1845 870 795 1655 780 685
0.50 125 1955 925 1005 1890 890 870 1765 835 770 1610 760 670
0.60 150 1885 890 975 1795 850 840 1695 800 750 1560 735 655
0.70 175 1800 850 955 1730 815 815 1605 760 720 1480 700 635
0.80 200 1700 805 930 1630 770 785 1520 715 695 1405 660 615
0.90 225 1575 745 895 1525 720 760 1395 660 660 1285 605 585
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
G50UH−60D−155−1, −2, −3 PERFORMANCE − Single Side Return Air − Air volumes in bold require field fabricated transition
to accommodate 20 x 25 x 1 in. (508 x 635 x25 mm) cleanable air filter in order to maintain proper air velocity.
External Static
Air Volume / Watts at Various Blower Speeds
Pressure
High Medium−High Medium−Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
0.00 0 2230 1050 1080 2130 1005 945 1995 940 840 1830 865 745
0.05 12 2200 1035 1070 2105 990 935 1970 930 830 1810 855 735
0.10 25 2165 1025 1060 2075 980 930 1950 920 820 1795 845 725
0.15 37 2135 1005 1050 2040 965 915 1920 905 815 1765 835 720
0.20 50 2100 990 1035 2005 945 905 1890 895 805 1735 820 710
0.25 62 2050 965 1015 1975 930 895 1855 875 795 1705 805 700
0.30 75 2000 945 995 1940 915 880 1820 860 780 1675 790 690
0.40 100 1905 900 965 1860 875 850 1755 825 770 1630 770 680
0.50 125 1825 860 945 1780 840 830 1700 800 750 1555 735 660
0.60 150 1745 825 920 1690 795 805 1595 750 715 1495 705 645
0.70 175 1650 780 905 1610 760 785 1515 715 705 1430 675 625
0.80 200 1565 740 880 1520 715 755 1445 680 680 1330 630 605
0.90 225 1445 685 845 1385 655 720 1300 610 640 1225 580 575
NOTE − All air data is measured external to unit with 1 in. (25 mm) cleanable filter (not furnished − field provided) in place. Also see Filter Air Resistance table.
